350cd/m2 10.1" 1280x800 Tft Lcd Display With Mipi Interface 40 Pins

Brand Name : BOE

Model Number : BP101WX1-400

Certification : CE,ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : $35

Payment Terms : T/T

Supply Ability : 5000pcs

Delivery Time : 3-5 work days

Packaging Details : Original packaging

Outline Dimension : 229.46(W)×149.15(H)×4.5mm

Active Area : 216.96(W)×135.6(H)mm

Number Of Pixels : 1280(RGB)×800

Luminance : 350cd/㎡

Operating TEMP : -20℃~+60℃

Storage TEMP : -30℃~+70℃

Contact Now

10.1" 1280x800 Tft Lcd Display With Mipi Interface 40 Pins

General Description:

The BP101WX1-400 has a display resolution of 1280 (RGB) x 800 (WXGA), an aspect ratio of 16:10 (W:H), and a vertical RGB strip arrangement of pixels. Its display area size is 216.96×135.6 (W×H) mm, exterior size is 229.46×149.15 (W×H)×4.5 (thick) mm, surface treatment is matte, anti-reflective treatment, product net weight 164.5/167g (Typ./Max.). The backlight of this product uses WLED light-emitting side entry light source (bottom), the life of the light source is 12K hours, including LED driver.

Specifications:

Parameter Specification Unit
Active Area 216.96(H)*135.6(V) mm
Number Of Pixels 1280(H)×800(V) pixels
Luminance 350 cd/m² (Typ.)
Pixel Arrangement Pixels RGB stripe arrangement
Display Mode Normally Black
Display Colors 16.7M(6bit +Hi-FRC) colors
Interface MIPI (4 data lanes) , 40 pins
Contrast Ratio 800:1(typ.)
Viewing Angle(CR>10) 80/80/80/80(typ.)
Response Time 30(typ.)/40(max.) ms
Color Gamut 50%NTSC
Weight 164.5/167g (Typ./Max.)
Outline Dimension 229.46(H)*149.15(V)*4.5(typ)(FOB -Panel) mm

Absolute Maximum Ratings:

Item

Symbol

 Values

Unit
Min. Max.
Operation Temperature TOP -20 60 ℃
Storage Temperature TST -30 70 ℃

350cd/m2 10.1" 1280x800 Tft Lcd Display With Mipi Interface 40 Pins

Handling Precautions:

1. Keep the LCD safe from vibration, shock and pressure.

2. Do not store the LCD near organic solvents or corrosive gasses.
